Smart Home, Low Voltage and Network Cabling Installation

We install Ring video doorbells wired to the building rather than left on a battery, and we handle the part most installations fail on: the power source behind the device.

A wired installation means checking what is already there — the bell wiring, the chime and the transformer feeding both — then mounting the device where it sees what you want it to see, at a workable height and angle, with the cable protected where it passes outside. Where there is no doorbell wiring at the door, that is a short new run rather than a reason to give up on a wired install.

Yes — a wired video doorbell is powered through a low-voltage transformer, usually the one already feeding the existing chime.

That transformer is the most common reason a doorbell installs and then misbehaves. Many were put in years ago to ring a mechanical chime and were never meant to supply a camera that streams. When the supply is marginal the symptoms look like device faults rather than power faults: the doorbell restarts, drops off the network, or records intermittently.

So before mounting anything we check the transformer against what the device requires, the condition of the existing bell wire, and what kind of chime is on the circuit. If the transformer cannot support the device we replace it; if the wiring is too far gone we say so before the device goes on the wall.

There are three honest ways to power a video doorbell, and the right one depends on the door rather than on preference.

• Existing doorbell wiring. The usual case: the device runs on the bell circuit, subject to the transformer and chime checks above.
• A new low-voltage run, for a door with no doorbell wiring or a position the wiring never reached. Straightforward at a front door, more involved where the route crosses finished walls.
• Battery. No wiring and no transformer question — but somebody has to take the device down to recharge it, and cold weather shortens the interval.

Cameras follow the same logic, with one addition: some are made to plug into a receptacle, which only helps if one exists where the camera needs to be.

A floodlight cam replaces a fixture, so the question is whether a supply already exists where you want it.

Where an exterior fixture is there it is usually a swap, plus the mounting and aiming that decides whether the camera is useful. Where there is no fixture at that corner — the common case, because the good camera position and the old floodlight position are rarely the same — it needs a supply run, and that is electrical work.

Security camera installation follows the same pattern for wired cameras generally, not only Ring: a route the cable can take, protection from weather and direct sun, a termination still sound in five years. Cameras fed over the network rather than by an adapter are network cabling work.

• Ring security devices and other camera systems. We install and power the equipment you have chosen. Much of a wireless kit is meant for the homeowner to place; where a component needs a supply, a transformer or a cable, that part is ours.
• Smart switches and dimmers, which need a neutral in the box and a dimmer matched to the load. An older box may have no neutral at all — a wiring conversation before it is a device conversation.
• Smart thermostats, including the common wire the existing cable usually lacks, the most frequent reason a thermostat install stalls.

This is the boundary we work to, stated plainly rather than discovered later.

We do the electrical installation: the power source, the transformer, the low-voltage wiring, the mounting and aiming, the exterior routing, and testing on site that the device powers up before we leave.

You and the device maker keep the rest: the app, the account, any subscription, cloud recording, notifications, firmware and monitoring. We are not a monitoring provider, we do not administer anyone’s account or platform, we do not resell devices, and we claim no partnership with any manufacturer.

We do this work in homes and businesses across Nashville, Brentwood, Franklin, Belle Meade, Forest Hills, Oak Hill, Bellevue, Mt. Juliet, Goodlettsville, Hendersonville, Gallatin and White House. Describe the door or corner you want covered and what is already there.

The other half of this page, and the reason cameras and access points work at the far end of a property.

• Ethernet drops and structured cabling — runs from a central termination point to what needs a real connection: offices, televisions, access points, cameras. Terminated at both ends, tested and labeled.
• Wireless access point cabling and placement, so coverage comes from hardware in the right places rather than one router working beyond its means.
• Phone, coax, speaker and security cabling, and the tidy-up of what is there — a labeled termination point instead of a knot in a cupboard.

Most of this work runs on low voltage or an existing circuit. Sometimes it does not. Where a device needs a supply of its own, that becomes a dedicated circuit installed to the same standard as any other circuit we run. Where the panel has no room or capacity left, that is a panel upgrade conversation, and we will say so rather than find a breaker space and hope — the same licensed work as the rest of our residential electrical services and commercial electrical services.

• A doorbell that restarts, drops off, or records intermittently.
• A camera or doorbell that works until it is cold, wet, or sunlit.
• No doorbell wiring at the door you want covered.
• A thermostat that will not install because there is no C wire.
• A smart switch that flickers, buzzes or refuses to dim.
• Dead zones no firmware update was going to fix.

Low voltage is treated as the easy end of this trade, and it is where the worst workmanship tends to live: staples through cable, unterminated runs, undersized transformers, line voltage sharing a box with data cable. It is all invisible, and it all comes back.

We work under Tennessee Electrical Contractor #82227 as a licensed, bonded and insured contractor with 25+ years in the trade, so the line voltage side of a smart-home job is done by the same person who does the low voltage side. Our hours are 5:00 AM to 7:00 PM, seven days a week, and estimates are free.

Talk to us about your setup, or see the full list of services.
